We stock a large selection of frames. Most frames are steel, but we also do Titanium, Carbon and even Aluminum! When not in stock, please contact us for delivery time!
Headset
When selecting a frame normally we give a suggestion for a matching headset in the Frame detail page. When including a frame prep, we install the headset, free of extra charge!
Frame Prep
Mounting headset and bottom bracket in a unprepped steel frame can result in premature bearing wear. Most production frames come unprepped, so be smart and include the Frame prep in your order!
We warmly welcome the legendary Ascent back into the Ritchey line-up. Inspired by the experiences of life, the new Ritchey Ascent invites you to chase your own life experiences out on those unexplored passes, winding roads and endless trails. The adventurous soul of the of the original Ascent remains, while expanding its adaptability with modern features and much-requested details.
Tom Ritchey loves experiencing all sorts of bicycle adventures - especially dirt – seeking out winding dirt roads, cruising along gravel lanes, and ripping flowy singletrack. He designed this latest version of the Ascent to be a do-it-all adventure bike so that others can share the same thrills of adventure while also enjoying the renowned Ritchey ride experience.The new Ascent is more adaptable than ever. The frame is tig-welded with heat-treated, triple-butted Ritchey Logic steel tubing that features rack and fender mounts and a multi-purpose mount under the downtube, while a new Ritchey steel fork offers up multi-purpose, rack, fender and dynamo light mounts. Other notable features of the new Ritchey Ascent include post-mount brake compatibility, 148mm spacing and an external seat collar.
Throw a mountain bike bar on it and some 27.5" wheels for more trail-oriented adventures. Or ride it with drop bars and 29" wheels for some longer distance rough road riding. However you choose to roll, your riding possibilities are limitless atop the new Ritchey Ascent.
Material: heat-treated, triple-butted Ritchey Logic steel tubing - TIG welded
Rack and fender mounts
Ultra-light forged and machined straight 1-1/8" headtube
WCS headset included (upper IS42/28.6 - 16mm stack height | lower IS42/30)
BOOST 148mm spacing (12mm alloy thru-axle included)
Replaceable stainless-steel derailleur hanger
27.2mm seat tube with replaceable seat collar (max torque setting: 6Nm)
Seat tube clamp size: 28.6mm (2.5Nm max for derailleur clamps and chain guides)
Bottom bracket: 73mm - English threaded
Can accommodate 1X or 2X chainrings (Side Swing front derailleur required for double)
Crankset min/max ring size - single: 24 to 40t / double: 24/34 to 28/38t
External cable routing (continuous housing)
Bottle mounts: 2
Multi-purpose mount underside of downtube
Follow rack manufacturer for fork maximum payload
Fork
Ritchey steel fork with multi-purpose, rack, fender and threaded crown port
1-1/8" straight steerer
BOOST 110mm spacing (15mm alloy thru-axle included)
Steerer length: 300mm
Axle-crown: 435mm
Rake/Offset: 52mm
Follow rack manufacturer for fork maximum payload
Tire Compatibility
Wheel and tire compatibility: 27.5" x 2.6" or 29" x 2.6" (depending on tire/rim manufacturer)
Frame max spacing: 78mm
Fork max spacing: 78mm
Brake Compatibility
Post-mount brakes: 180mm max front rotor / 160mm max rear rotor
Details
Sizes: S / M / L / XL
Frame weight: 2400g (size L - w/o thru-axle)
Fork weight: 1125g (with uncut steerer / not including axle)
Color: Sierra Red
Tom Ritchey welded up his first bicycle in his parents’ garage more than 50 years ago – when he was only 15-years old. Since then, he has continued riding, researching, designing, and building legendary bicycle frames and components that have inspired generations of cyclists to experience great rides, influenced legions within the bicycle industry, and have won countless championships.
To celebrate Ritchey’s 50th anniversary and Tom’s enduring and influential spirit of off-road adventure, the 50th Anniversary Outback proudly sports a Half Moon Blue paint scheme - an amazingly beautiful light blue to deep blue fade that truly moves the soul. Additionally, this limited-edition gravel rig is adorned with special Ritchey logos that reference the company's history and the influence Palo Alto, California has had on Tom.
Painstakingly TIG-welded with proprietary triple-butted Ritchey Logic steel tubing, the Outback frame delivers the legendary Ritchey ride quality that’s resilient over the harshest terrain and delightfully responsive when you want to open it up.
Road, off-road, trail, expedition, you name it...the 50th Anniversary Ritchey Outback is designed do it all.
Specs:
Material: heat-treated, triple-butted Ritchey Logic steel tubing - TIG welded
Rack and fender mounts
Ultra-light forged and machined straight 1-1/8" headtube
WCS headset included (upper IS42/28.6 - 16mm stack height | lower IS42/30)
142mm spacing (12mm alloy thru-axle included)
Replaceable stainless-steel derailleur hanger
27.2mm seat tube with integrated seat collar (max torque setting: 6Nm)
Seat tube clamp size: 28.6mm (2.5Nm max for derailleur clamps and chain guides)
Bottom bracket: 68mm - English threaded
Can accommodate 1X or 2X chainrings
Crankset min/max ring size - single: 36 to 46t / double: 46/30t to 50/34t
External cable routing
Bottle mounts: 3
New Ritchey Carbon Adventure Fork with multi-purpose, rack and fender mounts
1-1/8" straight steerer with integrated 45-degree crown race
100mm spacing (12mm alloy thru-axle included)
Steerer length: 300mm
Axle-crown: 393mm
Rake/Offset: 50mm
Fork max payload: 3kg per side
Wheel and tire compatibility: 700 x 48mm or 650 x 2.0in (depending on tire/rim manufacturer)
Frame max spacing: 58mm
Fork max spacing: 60mm
Flat-mount brakes front and rear: 140mm (160mm max - adaptors available separately)
Frame weight: 2,175g (size L - w/o thru-axle)
Fork weight: 445g (with uncut steerer / not including axle)
Updated for 2020, the new Outback now sports several practical and adaptable features that offer riders the ability to chase epic ride experiences beyond the end of the road and the end of the day. Rack and fender mounts help to keep things dry and expand the load-carrying capacity for longer bikepacking adventures, while clearance for 700c x 48mm or 650b x 2.0in tires opens up a whole new world of possibilities. The frame accepts flat-mount disc calipers, and the new all-carbon fiber Ritchey Adventure Fork with multi-purpose mounts on the legs gives you more places to stow the supplies you gather at the last cafe.
Painstakingly TIG-welded with proprietary triple-butted Ritchey Logic steel tubing, the Outback frame delivers the legendary Ritchey ride quality that’s resilient over the harshest terrain and delightfully responsive when you want to open it up.
Bikepacking, road, off-road, trail, expedition, you name it…the new Ritchey Outback is designed do it all.Specs:
Material: heat-treated, triple-butted Ritchey Logic steel tubing - TIG welded
Rack and fender mounts
Ultra-light forged and machined straight 1-1/8" headtube
WCS headset included (upper IS42/28.6 - 16mm stack height | lower IS42/30)
142mm spacing (12mm alloy thru-axle included)
Replaceable stainless-steel derailleur hanger
27.2mm seat tube with integrated seat collar (max torque setting: 6Nm)
Seat tube clamp size: 28.6mm (2.5Nm max for derailleur clamps and chain guides)
Bottom bracket: 68mm - English threaded
Can accommodate 1X or 2X chainrings
Crankset min/max ring size - single: 36 to 46t / double: 46/30t to 50/34t
External cable routing
Bottle mounts: 3
New Ritchey Carbon Adventure Fork with multi-purpose, rack and fender mounts
1-1/8" straight steerer with integrated 45-degree crown race
100mm spacing (12mm alloy thru-axle included)
Steerer length: 300mm
Axle-crown: 393mm
Rake/Offset: 50mm
Fork max payload: 3kg per side
Wheel and tire compatibility: 700 x 48mm or 650 x 2.0in (depending on tire/rim manufacturer)
Frame max spacing: 58mm
Fork max spacing: 60mm
Flat-mount brakes front and rear: 140mm (160mm max - adaptors available separately)
Frame weight: 2,175g (size L - w/o thru-axle)
Fork weight: 445g (with uncut steerer / not including axle)
Cutthroat is Salsa's Tour Divide-inspired drop bar bike, born on the endless ribbons of mixed surfaces the Great Divide Mountain Bike Route offers. The latest Cutthroat brings to market a more compliant fork, a wide range of drivetrain compatibility, a new direct-mount frame pack and more accessory mounts than ever. It’s all about covering long distances with speed and comfort.Specs:
Redesigned high-modulus carbon frame and fork for more ride compliance
69° head tube angle provides a longer wheelbase for greater stability
Class 5 Vibration Reduction System (VRS) for increased comfort
Cutthroat Carbon Deluxe Fork with Three-pack mounts and internal dynamo cable routing
Front and rear thru-axles with boost spacing
Flat mount brakes and internal cable routing on frame and fork
Dropper post-compatible with 1x and 2x drivetrains (2x mechanical drivetrains use external cable droppers)
New sizing with addition of a 52 cm size
Front Axle: 15mm Thru x 110mm
Rear Axle: 12mm Thru x 148mm
Fargo is Salsa’s steel drop-bar mountain bike that offers a winning combination of multiple wheel size compatibility; drivetrain options ranging from geared to belt drive to single speed; and cargo mounts galore. Set it up as a dreamy do-it-all steel bikepacking rig, or adapt it for each unique adventure—Fargo lets you keep your options open. Splittable Alternator 1.5 dropouts allow for multiple drivetrain setups, belt drive compatibility Firestarter Carbon 110 Deluxe fork with four sets of Three-pack mounts and internal dynamo cable routing Wheel size versatility to run 27.5+, 29, or 29+ platforms Fender mounts (maximum 29 x 2.2" tire clearance with fenders) Clearance for 29 x 3.0" tires without fenders (29 x 2.6" max on XS frames)
Headset:
Cane Creek 40
Journeyer is Salsa’s workhorse road and gravel adventure machine.
This versatile platform is a gateway to gravel riding. The confidence of
its redesigned aluminum frame and carbon fork attracts mixed-surface
riders, while its cargo capacity appeals to bikepackers. Journeyer’s
fender mounts, rack mounts, wheel size compatibility, and handlebar
options suit riders seeking a do-it-all bike.
6061-T6 alloy frame
Salsa Waxwing
carbon fork with fender mounts, Three-Pack mounts, mid-blade rack
mounts, dynamo routing, and abrasion-resistant plate.
Flat mount brakes
Internal cable routing with stealth dropper post routing
Top tube and down tube accessory mounts on frame hold ride essentials
Compatible with 700c and 650b wheels and tires
Frame fits tires up to 700c x 50 mm or 650b x 55 mm (27.5 x 2.1")
Waxwing fork fits tires up to 700c x 50 mm or 650b x 56.5 mm (27.5 x 2.25")
12 x 100 mm thru-axle front, 12 x 142 mm thru-axle rear
Stormchaser is Salsa’s gravel bike for any and all conditions. Ample tire clearance and single speed-ready Alternator Flat Mount dropouts will see you through the muddiest rides. Suspension fork and dropper post compatibility let you get wild with your route choices.
Frames arrive early May 2021! Specs:
6066-T6 aluminum frame with Class 5™ Vibration Reduction System (VRS)
High-modulus carbon fork with alloy steerer, 12 x 100mm thru-axle, internal cable and dynamo routing, Three-Pack mounts, fender and rack compatibility
Alternator Flat Mount dropouts capable of single speed or 1x geared drivetrain
Includes single speed and geared dropout plates
Three water bottle mounts in the main triangle on 56–61 cm frames, and two on 49–54.5 cm frames
Top tube mount for Salsa EXP Series Direct Mount Top Tube Bag and additional mount on underside of down tube
Internal cable routing, dropper post-compatible
Front Axle: 12mm Thru x 100mm
Rear Axle: 12mm Thru x 142mm
Max Tire Clearance: 700x47mm with Mudguards
Vaya is Salsa's road adventure and light touring bike, designed to
handle any road surface, from pavement to gravel to dirt. The tubing
selection and stable geometry across the line makes for a bike that
feels great unloaded or loaded for a fast tour, soaking up unpredictable
surfaces mile after mile, from one town to the next. Vaya is an
extremely versatile machine, always ready and able if the path turns
less than ideal.
CroMoly steel butted frame. Salsa-designed, triple-butted, and frame size-specific seamless Sanko CroMoly tubing
Salsa Vaya Carbon Waxwing fork features carbon fiber construction with an aluminum steerer tube. The feature-rich fork includes Three-Pack mounts, mid-blade low rider rack mounts, internal dynamo wire routing, and fender mounts
Clearance for 700c x 50 mm tires or 700c x 45 mm tires with fendersRear Axle: QR x 135mm, Front Axle: QR x 100mm Bottom Bracket:
68mm BSA, threaded
Warbird is Salsa's gravel race bike, built off years of experience racing in some of the nation’s premier gravel events. It's designed to survive and thrive on anything from the often-hazardous B-roads that make up much of the Midwest gravel scene to the fire roads that climb to the heavens on the coasts.Specs:
High-modulus carbon frame with rear thru-axle dropouts and rear rack compatibility via Rack-Lock seat collar (sold separately)
Class 5 vibration reduction system dramatically increases comfort
Waxwing carbon fork featuring a 12 x 100mm thru-axle, Three-Pack and fender mounts, mid-blade eyelets, dynamo cable routing, and flat-mount brake standard
Full-frame internal cable routing for Di2 and mechanical brakes
Toptube bag mounts on all sizes, 3 bottle mounts on sizes 56cm and up
Clearance for 40mm travel suspension forks and internal dropper post routing (1x set-ups only)
Enhanced geometry with added clearance for up to 700c x 45mm, or 650b x 54mm (2.1")
Headset included
First introduced back in 2007, and perhaps somewhat misunderstood at the time, the Singular Peregrine is back by popular demand. Although its drop-bar-big-tire-classic-styling essence is the same, it’s seen a few geometry tweaks and changes to bring it up to date, and it now sports thru-axles and flat-mount brakes. It also has a lovely new bi-plane fork that makes space for 29 x 2.0 or 27.5 x 2.3″ rubber and is offered in two different shades of blue.
The price is for the frameset, pictures are examples of builds made with this frame!
Specs:
Custom drawn double butted Columbus steel tubing
Lugged head tube and seat cluster
Flat mount 160mm brake fitment
12mm thru axles – 142mm rear spacing, 100mm front
Eccentric Bottom Bracket insert – 68mm BSA threaded shell.
Clearance for Shimano road width cranks with <48/34 chainrings
Tyre clearance for max 622x55mm (29×2.1”) or 584x65mm (27.5×2.3”)
Bolt on modular cable guides under down tube
Double chainring compatible
27.2mm seat tube diameter
1 ⅛” external bearing head tube (34mm ID) for straight steerer fork
Electrostatic Deposition (ED) anti-corrosion treatment
Four frame sizes from Small to Extra Large.
Two colour options:
The iconic Singular Light blue (RAL 5014) with ivory head and seat tube panels (only for pre-ordered frames)
Midnight Blue (RAL 5004) with ivory head and seat tube panels
The Fog Cutter is an endurance road/road sport design. Soma designed it to fit fatter tires, but the frame angles are more road bike than CX or gravel bike. It can float you over chewed up asphalt better than most bikes in this category. This is the frame you want for long days in the saddle and the most demanding commutes.• Tange Prestige double butted CrMo steel tubing; heat treated throughout• Road sport geometry• Rear rack & fender mounts• Tange Modular dropouts. Stock setup is for 142mm thru-axle hubs and flat mount disc brakes. Alternative styles available thru Tange/Long Shen.• Fork options: Matching straight blade carbon fork (alloy steerer, flat mount disc, 12 x 100 thru-axle hub) or lugged CrMo steel fork (CrMo steerer, IS disc mount, QR hub)• Tire clearance for 700c x38mm with fenders (some front derailleurs will limit tire clearance) and 650b x 42mm• Fits 1-1/8" headset (EC34/28.6|EC34/30 headsets)- 27.2mm post size- 7 sizes: 48, 51, 54, 56, 58, 61 and 66cm- Weight: 4.25 lbs (48cm); 4.5 lbs. (58cm)- Paint: Cerulean Blue
The Jawbone A-Type frame is the perfect platform to build drop bar mountain touring and bike packing rig. While it is still game for riding gravel and singletrack, it is in its element when packed up for your next adventure. Fork sold seperately.
More information about the iontroduction of this frame can be found in the Soma Blog. The folks at BikePacking.Com have alreadymade a comprehensive review of the JawBoneSpecs A-Type:
Tange Prestige heat-treated butted CrMo steel; butted CrMo rear end
Flat mount disc brake tabs on rear
Investment cast vertical dropout with replaceable stainless steel hanger. 12 x 142mm tru-axle
Front derailleur compatible (bottom pull)
Rear rack and fender eyelets
Two sets of bottle cage bosses; one set of cargo cage bosses on downtube
44mm headtube: Fits 1-1/8" steerer tubes and tapered steerer tubes with a headset swap
27.2mm post size/28.6mm frt. der. size/29.8mm seat collar, 73mm bottom bracket (English threads)
Tire Width Range: 27.5 x 47mm to 2.5” / 700c x 38mm to 29 x 2.25”
Color: Sage Green
Sizes: 650b only: 50cm, 52cm / 700c: 54cm, 56cm, 58cm, 61cm, 64cm
The Jawbone A-Type frame is the perfect platform to build drop bar mountain touring and bike packing rig. While it is still game for riding gravel and singletrack, it is in its element when packed up for your next adventure. Fork sold seperately.
More information about the iontroduction of this frame can be found in the Soma Blog. The folks at BikePacking.Com have alreadymade a comprehensive review of the JawBoneSpecs A-Type:
Tange Prestige heat-treated butted CrMo steel; butted CrMo rear end
Flat mount disc brake tabs on rear
Investment cast vertical dropout with replaceable stainless steel hanger. 12 x 142mm tru-axle
Front derailleur compatible (bottom pull)
Rear rack and fender eyelets
Two sets of bottle cage bosses; one set of cargo cage bosses on downtube
44mm headtube: Fits 1-1/8" steerer tubes and tapered steerer tubes with a headset swap
27.2mm post size/28.6mm frt. der. size/29.8mm seat collar, 73mm bottom bracket (English threads)
Tire Width Range: 27.5 x 47mm to 2.5” / 700c x 38mm to 29 x 2.25”
Color: Sage Green
Sizes: 650b only: 50cm, 52cm / 700c: 54cm, 56cm, 58cm, 61cm, 64cm
The original inspiration for the Wolverine was “monster cross”, but it is seriously so much more. Its geometry is stable enough for off road touring, but sporty enough for all-around adventure and gravel riding. With its sliding dropouts, you can run single-speed, derailleur gearing or hub gearing.
The primary differences between the 3.0 and v. 4 Type-A and B is a new 46cm size, an extra set of water bottle bosses, and additional stack height on most sizes. The Type-A ALSO adopts more modern standards such as 142mm rear thru-axle and a 44mm headtube that will fit 1-1/8 straight steerer or tapered steerer with the proper headset type. There is NO frame break for Belt-Drive like the B-Type has. (See chart for other differences between A and B)Specs A-Type:
Tange Prestige heat-treated CrMo tube set
Clearance for 700x45c tires w/ fenders
Rear hub spacing/type: 142 x12mm Thru-Axle
IRD Broski sliding dropouts allow for geared or single-speed builds
Optional Matching Fork: Unicrown straight blade 15mm thru-axle fork with cage bosses (1-1/8”)
(No lugged crown fork offered for the Type-A)
Braze-ons for rear rack and fenders (disc brake-compatible racks only)
Three sets of water bottle bosses
44mm headtube (Use ZS44/28.6-ZS44/30 headset for 1-1/8” steerers) (Use ZS44/28.6 -EC44/40 headsets for 1-1/8”-1-1/2” steerers)
Sizes: 46, 50, 52, 54, 56, 58. 60, 62 and 66cm (We recommend 650b tires on the 46cm)
2.2 Kg (frame)
Paint: Storm Blue
The original inspiration for the Wolverine was “monster cross”, but it is seriously so much more. Its geometry is stable enough for off road touring, but sporty enough for all-around adventure and gravel riding. With its sliding dropouts, you can run single-speed, derailleur gearing or hub gearing.
The primary differences between the 3.0 and v. 4 Type-A and B is a new 46cm size, an extra set of water bottle bosses, and additional stack height on most sizes.Specs B-Type:
Tange Prestige heat-treated CrMo tube set
Clearance for 700x45c tires w/ fenders
Rear hub spacing:135mm (10mm QR, can be upgraded to 142mm 12mm TA with different inserts )
Gates Carbon belt-drive compatible
IRD Broski sliding dropouts allow for geared or single-speed builds
Optional Matching Forks: A) lugged flat crown standard QR axle, Tange Infinity CrMo steel fork; double eyelets pannier rack and mini rack mounts. B) Unicrown straight blade 15mm thru-axle CrMo steel fork
Braze-ons for rear rack and fenders (disc brake-compatible racks only)
Three sets of water bottle bosses
1-1/8” size headtube
Sizes: 46, 50, 52, 54, 56, 58. 60, 62 and 66cm (We recommend 650b tires on the 46cm)
2.2kg (frame)
Paint: Moss Green
The original inspiration for the Wolverine was “monster cross”, but it is seriously so much more. Its geometry is stable enough for off road touring, but sporty enough for all-around adventure.
2023 brings us the 4.1 A-Type update which adopts the flat mount disc standard on the frame and optional CrMo fork.
The A-Type has more modern standards than the B-Type, such as 142mm rear thru-axle and a 44mm headtube that will fit 1-1/8 straight steerer or tapered steerer forks with the proper headset type. There is NO frame break for Belt-Drive on the A-Type Wolverine. (See chart in photo gallery for other differences between A and B)
Specs A-Type:
Tange Prestige heat-treated CrMo tube set
Clearance for 700x45c tires w/ fenders
Rear hub spacing/type: 142 x12mm Thru-Axle
IRD Broski sliding dropouts allow for geared or single-speed builds
Optional Matching Fork: Unicrown straight blade 15mm thru-axle fork with cage bosses (1-1/8”)
(No lugged crown fork offered for the Type-A)
Braze-ons for rear rack and fenders (disc brake-compatible racks only)
Three sets of water bottle bosses
44mm headtube (Use ZS44/28.6-ZS44/30 headset for 1-1/8” steerers) (Use ZS44/28.6 -EC44/40 headsets for 1-1/8”-1-1/2” steerers)
Sizes: 46, 50, 52, 54, 56, 58. 60, 62 and 66cm (We recommend 650b tires on the 46cm)
2.2 Kg (frame)
Paint: Orange
The original inspiration for the Wolverine was “monster cross”, but it is seriously so much more. Its geometry is stable enough for off road touring, but sporty enough for all-around adventure. With its sliding dropouts, you can turn it into a single-speed CX bike. With a split seatstay, it is compatible with the Gates Carbon Belt Drive.
The primary differences between the 4.0 and 4.1 is that the frame and forks now fit the flat mount brake standard.Specs B-Type:
Tange Prestige heat-treated CrMo tube set
Clearance for 700x45c tires w/ fenders
Rear hub spacing:135mm (10mm QR, can be upgraded to 142mm 12mm TA with different inserts )
Gates Carbon belt-drive compatible
IRD Broski sliding dropouts allow for geared or single-speed builds
Optional Matching Forks: A) lugged flat crown standard QR axle, Tange Infinity CrMo steel fork; double eyelets pannier rack and mini rack mounts. B) Unicrown straight blade 15mm thru-axle CrMo steel fork
Braze-ons for rear rack and fenders (disc brake-compatible racks only)
Three sets of water bottle bosses
1-1/8” size headtube
Sizes: 46, 50, 52, 54, 56, 58. 60, 62 and 66cm (We recommend 650b tires on the 46cm)
2.2kg (frame)
Paint: Lunar Rock Grey
Surly Cross Check Frameset - Gloss Black
The Surly Cross Check. A cross bike by design but with a strong utilitarian appeal. Comfortable, versatile, tough as nails.Specs:
Works with all single, double and triple road or mountain cranksets
Includes seatpost clamp, and dropout adjusting screws
100% Surly 4130 chromoly frame, main triangle is double-butted; 1-1/8" threadless brazed chromoly fork
Bosses front and rear for cantilever or linear-pull brakes, eyelets at the dropouts, dual water bottle mounts, and fully threaded through-blade fork eyelets for a front rack
Semi-horizontal dropouts with a derailleur hanger for geared or singlespeed drivetrains and/or wheelbase adjustability
Clearance to run 700c x 45mm tires; 40mm with fenders
The Disc Trucker shares the same great features as the standard Long Haul Trucker with the addition of disc brakes, to provide dependability on the daily commute or trans-continental excursion. It’s designed to go the distance, and the rack mounts enable it to haul a bunch of stuff. The frame features a low bottom bracket and long chainstays for comfort and stability.
For 2020 the Disc Trucker has a revised & updated geometry. The new Disc Trucker has slightly shorter chainstays that add more agility when riding unloaded or with only a few things. We increased the stack and the headtube height. With a larger stack comes reduced standover clearance. So, we massaged the numbers to net just as much (if not more) standover than the legacy model, but you may notice that not all sizes have a truly horizontal top tube.
The new dropouts are built around a 12mm thru-axle front and rear, and the bike is spaced at 100mm front and 142mm rear, with threaded axles. Specs:
100% 4130 chromoly steel frame and fork; main triangle double-butted, ED coated for increased life expectancy
Upper bosses and dropout eyelets for racks front and rear, fender eyelets, pump peg, spare spoke carrier, and three sets of water bottle cage mounts
The fork includes a routing hole for your dynamo hub. This isn’t earth-shattering, but proper placement cleans up the front end quite a bit.
Chainring clearance max: 42/53t double, 38/52/56t triple
51mm IS disc mounts, designed to be used with 160mm rotors only
Clears a 26 x 2.1" tire with or without fenders
Rear brake mounting between seat stay and chain stay for zero interference with fenders or racks
The new dropouts are built around a 12mm thru-axle front and rear
The bike is spaced at 100mm front and 142mm rear, with threaded axles.
Still compatible with triple cranks for when you need all the gear range you can get!
Rohloff internally geared hub compatible using the upper rack mount on the NDS dropout. The boss is sized to mimic an M6 bolt head and index perfectly with an OEM2 axle plate. A chain tensioner will be necessary.
More info can be found at Surly Bikes
The Disc Trucker shares the same great features as the standard Long Haul Trucker with the addition of disc brakes, to provide dependability on the daily commute or trans-continental excursion. It’s designed to go the distance, and the rack mounts enable it to haul a bunch of stuff. The frame features a low bottom bracket and long chainstays for comfort and stability.
For 2020 the Disc Trucker has a revised & updated geometry. The new Disc Trucker has slightly shorter chainstays that add more agility when riding unloaded or with only a few things. We increased the stack and the headtube height. With a larger stack comes reduced standover clearance. So, we massaged the numbers to net just as much (if not more) standover than the legacy model, but you may notice that not all sizes have a truly horizontal top tube.
The new dropouts are built around a 12mm thru-axle front and rear, and the bike is spaced at 100mm front and 142mm rear, with threaded axles. Specs:
100% 4130 chromoly steel frame and fork; main triangle double-butted, ED coated for increased life expectancy
Upper bosses and dropout eyelets for racks front and rear, fender eyelets, pump peg, spare spoke carrier, and three sets of water bottle cage mounts
The fork includes a routing hole for your dynamo hub. This isn’t earth-shattering, but proper placement cleans up the front end quite a bit.
Chainring clearance max: 42/53t double, 38/52/56t triple
51mm IS disc mounts, designed to be used with 160mm rotors only
Clears a 26 x 2.1" tire with or without fenders
Rear brake mounting between seat stay and chain stay for zero interference with fenders or racks
The new dropouts are built around a 12mm thru-axle front and rear
The bike is spaced at 100mm front and 142mm rear, with threaded axles.
Still compatible with triple cranks for when you need all the gear range you can get!
Rohloff internally geared hub compatible using the upper rack mount on the NDS dropout. The boss is sized to mimic an M6 bolt head and index perfectly with an OEM2 axle plate. A chain tensioner will be necessary.
More info can be found at Surly Bikes
The Midnight Special is a road plus compatible frame, designed to provide comfort and speed on those all-day rides that extend well beyond fresh pavement. It excels on pot-holed, deteriorating pavement and the occasional long stretch of gravel. The Midnight Special matches perfectly with 650b road plus tires, ready to eat up road chatter and absorb all the bumps in the road for a much more comfortable ride.Specification:
100% Surly 4130 CroMoly frame, main triangle is double-butted; 1-1/8" threadless CroMoly fork
44mm head tube
Clearance for 650b x 60mm or 700c x 42mm tires without fenders (650b x 50mm or 700c x 32mm with fenders)
Wheel Size: 650b+ , 700c
Front Axle: 12mm Thru x 100mm, Rear Axle: 12mm Thru x 142mm
Rear dropouts: 12mm vertical dropout with derailleur hanger, 142x12mm thru-axle compatible or 135 x 10mm with Surly 10/12 adapter Washer (HU0001)
Brake compatibility: Flat-Mount disc, 160mm max rotor size
Braze-ons: Surly Triple Guides on top tube, single cable guides on down tube for full length cable housing. Two sets of Three-Pack mounts seat tube bottle mount (M–XL), upper seatstay threaded barrel bosses.
Seatpost: 27.2mm, Seatpost clamp: 30.0mm (Surly stainless included)
Headtube: 44mm I.D. Recommend EC44 lower cups. Zero Stack on top is o.k.
Front derailleur: 28.6mm, bottom-pull
Bottom bracket shell: 68mm shell width, threaded standard English (1.37" x 24t)
Chainring clearance: Singlespeed 44t; 34/50t
Tire clearance: 27.5 x 2.35", 700c x 42mm
Cargo weight limit: 400 lb combined rider and cargo. Max cargo 200 lb when properly loaded and mounted on suitably strong racks or frame bags.
FORK COMPATIBILITY:
Stem clamp: 28.6mm
Tire clearance: 27.5 x 2.35", 700c x 42mm
Crown race: 30mm
Front brake rotor: 51mm I.S., 180mm max rotor size
Front spacing: 100mm, Axle type: 12mm TA
Braze-ons: Two sets of Three-Pack mounts; mid-and low-blade fully threaded through-blade fork eyelets
The Midnight Special is an endurance road bike designed to provide comfort and speed on those all-day rides that extend well beyond fresh pavement. It excels on pot-holed, deteriorating pavement and the occasional long stretch of gravel. The Midnight Special’s 700c tires eat up road chatter and absorb all the bumps in the road for a much more comfortable ride. 100% Surly Chromoly frame, main triangle is double-butted; 1-1/8" threadless Chromoly fork Rack, fender, and three sets of water bottle mounts Flat-Mount disc brakes 44mm head tube Tire Clearance: 27.5 x 2.35" (w/o fenders), 700c x 42mm (w/o fenders), 650b x 50 (w/ fenders), 700c x 38mm (w/ fenders
The Ogre can get you to your job during the week, then way out of town on the weekend. It’s not sluggish on pavement or gravel and can also hold its own on singletrack. Ogre has many of the same features as Troll — horizontal slotted dropouts with Gnot-Boost spacing, a tweaked non-suspension corrected geometry, and a beefy tire clearance — but in a 29er platform.Specs:
Surly 4130 chromoly steel, main triangle double-butted frame
TIG-welded, Horizontal slotted with derailleur hanger, Gnot-Boost spacing allows the use of 135mm QR hub, 142 x 12mm thru-axle or 148 x 12mm Boost hubs. Features Rohloff torque arm slot and threaded eyelets for fenders, racks and Surly trailer mounts
Full-length Surly Trip Guide housing line guides for derailleurs and brakes; two sets of bottle cage mounts; upper seatstay threaded barrels, mid- and low-blade fully threaded through-blade fork eyelets; threaded holes for racks, fenders and trailer mounting nuts; Rohloff OEM2 axle plate mounting slot
Disc brakes only. Disc mounts are 51mm IS. Note: rear disc brake is limited to 160mm maximum rotor diameter and requires the use of Surly caliper adaptor (included with frames and bikes)
Frame is ED Coated for increased life expectancy
Tire clearance for 29 x 2.5” or 27.5 x 3”
Frame Material: Steel
Fork Material: Steel
Color: Pile of Bricks
Defined Color: Light Blue
Front Axle: QR x 100mm
Rear Axle: 12mm Thru x 148mm
The Ogre can get you to your job during the week, then way out of town on the weekend. It’s not sluggish on pavement or gravel and can also hold its own on singletrack. Ogre brings several sensible features to the 29er platform, including horizontal slotted dropouts with Gnot-Boost spacing, a tweaked non-suspension corrected geometry, and a beefy tire clearance.
100% Surly Chromoly steel, double-butted main triangle
TIG welded, Horizontal slotted with derailleur hanger, Gnot-Boost spacing allows the use of 135mm QR hub, 142 x 12mm thru-axle or 148 x 12mm Boost hubs. Features Rohloff torque arm slot and threaded eyelets for fenders, racks and Surly trailer mounts
Full-length Surly Trip Guide housing line guides for derailleurs and brakes; two sets of bottle cage mounts; upper seatstay threaded barrels, mid- and low-blade fully threaded through-blade fork eyelets; threaded holes for racks, fenders and trailer mounting nuts; Rohloff OEM2 axle plate mounting slot Disc brakes only. Disc mounts are 51mm IS. Note: rear disc brake is limited to 160mm maximum rotor diameter and requires the use of Surly caliper adaptor (included with frames and bikes)
Frame is E.D. coated for increased life expectancy
Tire clearance for 29 x 2.5" or 27.5 x 3"
