Soma Wolverine Frame V4.1 - Type A - Orange
€ 1.179,00
Beschikbaar in 21 dagen, levertijd 2-5 days
Productinformatie "Soma Wolverine Frame V4.1 - Type A - Orange"
The original inspiration for the Wolverine was “monster cross”, but it is seriously so much more. Its geometry is stable enough for off road touring, but sporty enough for all-around adventure.
2023 brings us the 4.1 A-Type update which adopts the flat mount disc standard on the frame and optional CrMo fork.
The A-Type has more modern standards than the B-Type, such as 142mm rear thru-axle and a 44mm headtube that will fit 1-1/8 straight steerer or tapered steerer forks with the proper headset type. There is NO frame break for Belt-Drive on the A-Type Wolverine. (See chart in photo gallery for other differences between A and B)
Specs A-Type:
- Tange Prestige heat-treated CrMo tube set
- Clearance for 700x45c tires w/ fenders
- Rear hub spacing/type: 142 x12mm Thru-Axle
- IRD Broski sliding dropouts allow for geared or single-speed builds
- Optional Matching Fork: Unicrown straight blade 15mm thru-axle fork with cage bosses (1-1/8”)
- (No lugged crown fork offered for the Type-A)
- Braze-ons for rear rack and fenders (disc brake-compatible racks only)
- Three sets of water bottle bosses
- 44mm headtube (Use ZS44/28.6-ZS44/30 headset for 1-1/8” steerers) (Use ZS44/28.6 -EC44/40 headsets for 1-1/8”-1-1/2” steerers)
- Sizes: 46, 50, 52, 54, 56, 58. 60, 62 and 66cm (We recommend 650b tires on the 46cm)
- 2.2 Kg (frame)
- Paint: Orange
Headset
The 40-Series is the workhorse of Cane Creek's headset line-up. Representing the balance of performance, durability and value, the series incorporates all the features necessary for a robust, lightweight, long-lasting headset. Zero stack uppers press into head tube with very little stack height. Lowers are either zero stack or external cup. Sealed black oxide bearings Carbon-friendy compression ring captured in top cover, keeping shims in place Steel crown race with integrated seals Interlok spacer compatible Compatible with straight steerer 1-1/8" forks Weight: 171 g Upper Stack Height: 8 mm Lower Stack Height: 12 mm Crown Race: 30 S.H.I.S Lower: EC44 S.H.I.S Upper: ZS44 S.H.I.S. Stem Clamp Diameter: 28.6 Threadless
Cane Creek Balhoofd 40 ZS44/28.6 | EC44/40
Slotting immediately in between the Forty series and Hellbender 70 headsets, Fifty series brings a new, modern aesthetic while maintaining a relatively affordable price. Additional machining on the top cover and cups along with refined, laser-etched graphics give the headset a sharper, more angular appearance that feels more appropriate for today’s bike.Specs: Cups & Covers: 6061 T-6 Aluminum, Internally relieved to reduce weight Bearings: ZN40 sealed cartridge bearings, zinc-coated for corrosion resistance Sealing: Steerer tube o-ring seal, low friction top cover lip seal, co-molded crown race lip seal Compression Ring: Carbon-friendly compression ring retained in top cover Crown Race: Steel forged, then machined for increased hardness & durability Spacers: Compatible with Cane Creek Interlok spacers + traditional spacers Stack Heights: External Cup (EC) — 15mm top, 11mm bottom ZeroStack (ZS) — 8mm top, 4mm bottom Integrated (IS) — 9mm top, 1mm bottom
Slotting immediately in between the Forty series and Hellbender 70 headsets, Fifty series brings a new, modern aesthetic while maintaining a relatively affordable price. Additional machining on the top cover and cups along with refined, laser-etched graphics give the headset a sharper, more angular appearance that feels more appropriate for today’s bike. Specs: Cups & Covers: 6061 T-6 Aluminum, Internally relieved to reduce weight Bearings: ZN40 sealed cartridge bearings, zinc-coated for corrosion resistance Sealing: Steerer tube o-ring seal, low friction top cover lip seal, co-molded crown race lip seal Compression Ring: Carbon-friendly compression ring retained in top cover Crown Race: Steel forged, then machined for increased hardness & durability Spacers: Compatible with Cane Creek Interlok spacers + traditional spacers Stack Heights: External Cup (EC) — 15mm top, 11mm bottom ZeroStack (ZS) — 8mm top, 4mm bottom Integrated (IS) — 9mm top, 1mm bottom
Slotting immediately in between the Forty series and Hellbender 70 headsets, Fifty series brings a new, modern aesthetic while maintaining a relatively affordable price. Additional machining on the top cover and cups along with refined, laser-etched graphics give the headset a sharper, more angular appearance that feels more appropriate for today’s bike.Specs: Cups & Covers: 6061 T-6 Aluminum, Internally relieved to reduce weight Bearings: ZN40 sealed cartridge bearings, zinc-coated for corrosion resistance Sealing: Steerer tube o-ring seal, low friction top cover lip seal, co-molded crown race lip seal Compression Ring: Carbon-friendly compression ring retained in top cover Crown Race: Steel forged, then machined for increased hardness & durability Spacers: Compatible with Cane Creek Interlok spacers + traditional spacers Stack Heights: External Cup (EC) — 15mm top, 11mm bottom ZeroStack (ZS) — 8mm top, 4mm bottom Integrated (IS) — 9mm top, 1mm bottom
The Midnight Special is an endurance road bike designed to provide comfort and speed on those all-day rides that extend well beyond fresh pavement. It excels on pot-holed, deteriorating pavement and the occasional long stretch of gravel. The Midnight Special’s 700c tires eat up road chatter and absorb all the bumps in the road for a much more comfortable ride. 100% Surly Chromoly frame, main triangle is double-butted; 1-1/8" threadless Chromoly fork Rack, fender, and three sets of water bottle mounts Flat-Mount disc brakes 44mm head tube Tire Clearance: 27.5 x 2.35" (w/o fenders), 700c x 42mm (w/o fenders), 650b x 50 (w/ fenders), 700c x 38mm (w/ fenders
At White Industries, they always strive to make the highest quality products and our Headsets are no exception. This product has been designed with the user in mind in a few ways. Easy to service, clean, and adjust your headset. For durability, the headsets are made with stainless steel bearings and aluminium cups to give you corrosion resistance and strength. All this has been done to create a headset you can rely on wherever your bike takes you.
Frame Prep
Bij het voorbereiden van een frame wordt voor verzenden: het balhoofd en bottom bracket geruimd en gevlakt de vorkkroon gevlakt op verzoek een headset en/of bottom bracket geïnstalleerd. Waarom zou je een frame en vork willen ruimen en vlakken? Als we de cups van een headset of bottom bracket monteren dan willen we dat deze cups precies vlak en parallel gemonteerd worden. De meeste frame buizen zijn wél recht gelast maar niet altijd perfect parallel afgezaagd. Ook framelak kan ervoor zorgen dat de cups niet perfect parallel gemonteerd kunnen worden. Door beide uiteinden van de framebuizen te ruimen en te vlakken zorgen we ervoor dat de cups maximaal parallel gemonteerd kunnen worden. Hierdoor hebben we minimale speling en gaan de lagers veel langer mee.
