Velocity USA Rims -
Velocity USA has been a performance aluminum rim manufacturer for over 25 year! They are now located in Grand Rapids, Michigan, where they manufacture rims and wheels for anyone passionate about bikes! The rim extrusion is sourced from Profile Precision Extrusions in Arizona, and they roll, drill, anodize, build and distribute their rims and wheels from their Grand Rapidsfactory.
Velocity A23 700c OC MswThe A23 OC rim is the off center version of the popular A23. Off center design allows for dramatically improved spoke tension on a dished wheel. With a wider footprint, the A23 OC allows for a more aerodynamic rim/tire combination when paired with a 23c tire. The tire profile mimics the characteristics of a tubular, gaining increased control and lower rolling resistance without the inconvenience of tubular glue or the dangers of irreparable roadside mechanicals. A tubeless ready design makes this rim ideal for road and cyclocross applications.
Tight tolerances require the use of a low profile rim tape like Velotape to avoid tire installation issues. Veloplugs are not recommended on A23 or A23 OC rims.
3.0mm offsetRim Size: 700c Width: 23mm Height: 19.5mm Optimal Tire Width: 23mm - 35mm Tire Interface: Clincher / Tubeless Valve: Presta 32 - 40mm Bead Seat Diameter (BSD): 622 Effective Rim Diameter (ERD): 601 Weight: 460g
Velocity Aileron 700c
Features a disc specific elliptical profile designed with aerodynamics and weight as key factors. Specifically tuned to be aerodynamically paired with 23-28c road tires, though a 20mm inner width compliments even the most voluminous gravel and ‘cross tires.
Tubeless ready.
Tight tolerances require the use of a low profile rim tape like Velotape to avoid tire installation issues. Veloplugs are not recommended on Aileron rims.
Velocity Atlas
The Atlas is one of our heavier duty rims with a boxy profile which
provides a classic look while preventing dings to the rim and preventing
pinch flats. As the only rim that we eyelet, it looks great on that
vintage bike that you're looking to restore! The eyelets give you a
smooth surface that works with your spoke nipples to create a wonderful
build. Designed with commuting, touring, for heavier riders with heavier
loads, and city-riding in mind, it pairs well with so many more
applications.The Atlas is not machined to leave as much material as
possible on the sides of the rim - giving you the longest lasting wear
and tear rim brake option that we provide. Rim brakes or disc brakes,
this is a great option if you're looking for something stylish that
withstands your road miles through out the year. Due to the way in which
we join this rim, we can only offer anodized Silver or polished, black
and custom colors are not an option. Specs: Rim Size: 700c Width: 25.4mm
Height: 18mm Optimal Tire Width: 28mm - 45mm Tire Interface: Clincher / Tubes Only, Valve: Presta 32 - 40mm Bead Seat Diameter (BSD): 622, Effective Rim Diameter (ERD): 605 Weight: 620g
Velocity Blunt 35 26”
The '35' part is a reference to its astounding width, which gives any wheel built with it a larger footprint, and so, more traction. Very useful for cross-country and all-mountain riders who are looking for lateral stiffness without so much weight
Rim Size: 26" Width: 35mm Height: 22mm Optimal Tire Width: 50mm - 70mm Tire Interface: Clincher / Tubeless Valve: Presta 32 - 40mm Bead Seat Diameter (BSD): 559 Effective Rim Diameter (ERD): 534 Weight: 530gPlease:
These rims are only available on special order, delivery normally 4-9 weeks.
Velocity Blunt 35 27.5”
The '35' part is a reference to its astounding width, which gives any wheel built with it a larger footprint, and so, more traction. Very useful for cross-country and all-mountain riders who are looking for lateral stiffness without so much weight
Rim Size: 27.5" Width: 35mm Height: 22mm Optimal Tire Width: 50mm - 70mm Tire Interface: Clincher / Tubeless Valve: Presta 32 - 40mm Bead Seat Diameter (BSD): 584 Effective Rim Diameter (ERD): 558 Weight: 555g Disc Only
Velocity Blunt 35 29”The '35' part is a reference to its astounding width, which gives any wheel built with it a larger footprint, and so, more traction. Very useful for cross-country and all-mountain riders who are looking for lateral stiffness without so much weight
Rim Size: 29" Width: 35mm Height: 22mm Optimal Tire Width: 50mm - 70mm Tire Interface: Clincher / Tubeless Valve: Presta 32 - 40mm Bead Seat Diameter (BSD): 622 Effective Rim Diameter (ERD): 596 Weight: 590g Disc Only
Blunt SS Rim
I-beam bead hook maximizes internal width for optimum tire performance
Advanced spoke bed design allows for super high tension wheels, while keeping overall rim weight low
Precision diameter and bead seat design
Brake Track: None
Valve: Presta
Rim Width (Internal): 26.6
Defined Color: Black
Rim Material: Alloy
Tire Type: Tubeless Ready , Clincher
Rim Center Offset (mm): 0
